Applications
	GSM/CDMA/PCS/3G/WLAN 698 to 2700MHz band
	Features
	Broadband, Low VSWR Sealed with radome, strong protection Supplied with mast down-tilt bracket
Specifications
Model			GA-LTE-YG-698-2700-9
Frequency Range-MHz			698-960		1710-2700
Vertical Beamwidth-degree			50		40
Horizontal Beamwidth-degree			65		50
F/B Ratio-dB			≥15		≥18
Gain-dBi			9		11
VSWR			≤1.5
Impedance-ohm			50
Intermodulation-dBm			≤-135dBc(2×10W)
Polarization			Vertical
Maximum Power-W			50
Connector			N type or customized
Dimensions-mm			445×265×65
Weight-Kg			0.6
Mounting Mast Diameter-mm			40-50
