SPECIFICATION
Dieletric Antenna
Center Frequency 1575.42 MHz±3 MHz
V.S.W.R 1.5 : 1
Band Width ±5 MHz
Impendence 50 ohm
Polarization Type RHCP

LNA / Filter
LNA Gain(Without cable) 30 dB Typical
Noise Figure 1.5 dB
DC Voltage 2.2~5 V
DC Current 5~15 mA

GSM Antenna
Frequency 824~894 MHz / 1710~1990 MHz
880~960 MHz / 1710~1990 MHz
V.S.W.R(5m) 2.0 : 1
Impendence 50 ohm
Typical Gain 2 dBi

WiFi Antenna
Frequency 2400~2500 MHz
V.S.W.R(5m) 2.0 : 1
Impendence 50 ohm
Typical Gain 3 dBi

Mechanical
Cable RG174 3m / 5m or others
Connector SMA / SMB / MCX or others
Housing Black or others

Environmental
Working Temp -40~+85
Humidity 55%~75%RH
Waterproof IP67
