ITEM

MODEL

WP50-40 24Z

WP50-50 24Z

WP50-6024Z

WP50-40 48

WP50-50 48

WP50-60 48

Rated charge current

40A

50A

60A

40A

50A

60A

Rated load current

40A

50A

60AMP

40A

50A

60AMP

System voltage

12/24V AUTO work

48V

Protection

Over load

��150% of rated current for 60 sec.for load and solar panel

Shortcircuit

Over 300%, shut offat noce.for load and solar panel

Over voltage

17V;2*17V;4*17V for DC load

Low Voltage Disconnection(LVD)

10.7V/21.4V

42.8V

Low Voltage Reconnection(LVR)

12.5V/25.0V

50.0V

Reverse polarity

protection forsolar panel ,battery andDCload.

Reverse current

yes.at night

Lighting protection

yes

Static current

�� 30mA

Voltage drop

Loop Voltage Drop

��200mV

Charging voltage

Boost charging

14.8V;2*14.8V ;4*14.8V for 30 Mins.Only for Battery was over discharged.

Equalizing charging

14.4V; 2*14.4V ;4*14.4V for 30mins

Open Circuit Voltage of solar panel

��50V

��100V

Float charge

13.7V/27.4V

54.8V

Charging recovery

13.2V; 2*13.2V

Temperature compensation

-4mV/Cell/��

Battery low

12V; 2*12V;4*12V

Load disconnect voltage

11.4V; 2*11.4V;4*11.4V

Over discharge forced recovery

12.5V��25.0V��50V ( recovery by switch )

Charging control mode

PWM mode

Running temperature

-20��~ 50��

Storage temperature

-30��~ 70��

Humidity requirements

��90��,no condensation

Installation cable area

>3# AWG ( 25mm )2

Protection class

IP22

Case material

ABS

LCD display

Charging,Discharging , Battery & Solar Panel state and Load working Mode

Product size(mm)

130mm 188mm 62 mm

Product Weight

590g

Carton size(mm)

570*420* 230 mm

Carton weight(kg)

18KG/24PCS

Notes

with ��Z�� -- automatic identify voltage level,��T�� represent controller with remote monitoring.
