●With Stabilizer Function

●Wide Input Voltage Range

●Wide Input Frequency Range

●High/Low Voltage Protection, Overload/Short Protection

●Cool start computer even there isnt main power

●Automatic recharge even UPS is off

●Automatic restart

●Beeping Alarm on Battery, Battery Low and Overload

●Beeping Selection

●Intelligent Battery Management

●Intelligent LCD Display

●Smart RS232& RJ11& USBOption

●Compatibility with generators

Product	Requirements	Model 1	Model 2	Model 3	Model 4	Model 5	Model 6
Power (VA)		PCA-500	PCA-650	PCA-800	PCA-1000	PCA-1200	PCA-1500
Input	Voltage	80-150VAC　/ 145-290VAC　±5V
	Frequency	60/50Hz+/-10%
Output	Voltage (AC Mode)	105-135VAC　/　190-250VAC
	Voltage (Inverter Mode)	120VAC / 220VAC ±5%
	Capacity	500VA/300W	650VA/360W	800/480W	1000VA/600W	1200/720W	1500VA/880W
	Frequency (Inverter Mode)	60/50Hz+/-0.5Hz
	Transfer Time	2ms typical
	Generator connection	Normal Working under the Generator
	Waveform	modified-Sinewave
Protection	Spike & Surge Suppression	yes
	Over/Under Volt.	Switch to Bat.O / Pwhen Mains over regulation range
	Over load /short Circuit	Fuse & current limited for both Mains and Battery modes
Battery	Type	Lead-Acid maintenance-free
	Dc Bus	12V7.0Ah		12V9.0Ah	12V7.0Ah		12V9.0Ah
	Number	1 PC		1	2 PCS
	Recharge time	8hours≥90%
	Back up time(one PC)	8-15mins	10-18mins	15-25mins	20-30mins	20-30mins	25-45mins
Physical	Weight (KGs)	5	5.5	6	10.5	11	11.5
	ShippingWt.	5.6	6	6.5	11	11.5	12
	Product Dimensions (mm)	335*95*160			355*120*195
	Packing Dimensions (mm)	395*360*230 mm/ 2 PCS in 1 Carton			435*395*275/ 2 PCS in 1 Carton
Soft ware	RS232 or USB optionWindows & NT	Auto save & shut down
Function	Cold start	UPS Start The Computer Even there Is no Main Power
	Automatic Charge	Automatic Charge when UPS is off
	Automatic Restart	Automatic Restart if main power coming within one hour
	Voltage display	220v/230v Optionalfollowing the real capacity
	Frequency	50HZ/60HZ Optioanl following the real
	Beeping	During the battery mode ,the beeping optional
Efficiency	AC-AC	1
	DC-AC	0.6
Acoustic	Noise level	≤45dB
Environmental	Temperature	-5-45 DegreeC
	Humidity	20% to 90%
Power Outlets	No. and types	2SOCKETS			3 SOCKETS
