| structure |
Item |
spec |
| ID style |
fashion |
| net weight |
39g |
| size |
37*45.5mm |
| button |
four buttons ,2 the family number , SOS key, turn on/off button |
| panel |
0.66 inch LCD |
| gps antenna |
high sensitivity ceramic antenna |
| GSM antenna |
LDS |
| battery |
400mAm |
| SIM card |
1 |
| gravity sensor |
support |
| I/O prot |
Thimble charger |
| waterproofing grade |
IP54 |
| |
| Hardware |
Chip |
MTK MT6261 |
| GPS chip |
MTK3336 |
| GPRS |
Class12 |
| GPS signal |
L1,1575.42MHz C/A code |
| GPS number of channels |
20 channels |
| GPS Chip receiver sensitivity |
Tracking sensitivity：-159dBm，Acquisition sensitivity：-143dBm |
| GPS Positioning accuracy |
5～15 meters |
| LSB positioning accuracy |
100-1000M |
| The minimum standby current |
<0.5 mA |
| The average standby current |
<2.5 mA |
| Average operating current |
< 55mA |
| Working temperature |
-20～70℃ |
| Operating humidity |
5% to 95% Solidification |
| Testing and certification |
Can pass the CAT, 3C and CE |
| GPS Antenna |
Built-in high sensitive ceramic antenna |
| GSM Antenna |
Built-in 850/900/1800/1900MHz PIFA antenna |
| Bluetooth |
NO Supported |
| Gravity sensor |
Compatible |
| Speaker |
1609 speaker |
| MIC |
Supported |
| Tamper |
Optional |
| |
| Software |
Support operating system |
Android 2.3 and above,IOS5.0 and above |
| Call |
Two way communication（Support listening mode） |
| Language |
Simple Chinese, English |
| GSM+GPRS+GPS |
GPS+LBS dual-mode positioning |
| Support AGPS |
Cold boot, locate in 26 seconds |
| Communication functions |
Interference-free mode, family number forced answer automatically, listening to the surrounding enviroment. |
| Power manager |
Ultra low power management, intelligent dormancy |
| SOS one button |
One button SOS, dial automatically |
| Intelligent defence |
Beyond the setting range will send alarm automatically |
| The historical track |
Save the historial track for last 3 months |
| Online upgrade |
Software remote upgrade, remote debugging and maintenance, remote set parameters. |
