Projection system |
Single LCD technology |
|
|
Projection Method |
Front/ceiling mount |
|
|
LCD |
|
|
|
Size |
7.0” |
|
|
Driving method |
Poly-silicon TFT Matrix |
|
|
Pixel number |
854×480 LCD |
|
|
Native resolution |
WVGA(support VGA,SVGA) |
|
|
Aspect ratio |
16:9 (support 4:3) |
|
|
Color reproduction |
16.7 mil |
|
|
Projection Lens |
|
|
|
Material |
All glass |
|
|
Type |
Manual |
|
|
F-number |
3.0 |
|
|
Focal length |
f=200mm |
|
|
Lamp |
|
|
|
Type |
150W HID |
|
|
Life |
>6000H |
|
|
Screen Width Ratio |
|
|
|
Screen size(projection distance) |
60’-120’(1.9m-3.6m)(at 16:9) |
|
|
Keystone Correction |
Vertical +15 degrees |
|
|
Brightness (Typical) |
900/1200 ANSI Lumens |
|
|
Contrast Ratio |
600 ：1 |
|
|
Audio Output |
1W Monaural |
|
|
Power Supply Voltage |
180~220V/50(60)Hz AC |
|
|
Warning-System |
Warning-by-voice system (Chinese/English) |
|
|
Dimensions(excludes lens and feet) |
297(W)×250(L)×115(H)mm |
|
|
Package/pcs |
383(L)× 390(W)× 242(H)mm |
|
|
|
720PCS/20” CONTAINER |
|
|
Weight(net) |
4.8kg |
|
|
Remote Control |
All Functions included |
|
|
Input Terminal |
|
|
|
Video/Audio |
RCA×2(White/Red) |
|
|
S-video |
S-Video×1 |
|
|
RGB |
Mini 15 pin×1 |
|
|
Native |
854×480 |
|
|
Resize |
640×480;800×600(recommended),1024×768 |
|
|
Cable TV |
(optional)(All TV modes) |
|
|
Input Signal |
RGB,PAL, NTSC,SECAM, HDTV |
|
|
Output Terminal |
|
|
|
Audio |
RCA×1( valid in TV mode) |
|
|
Warranty |
One-year limited warranty( lamp included), |
|
|
Body color |
Pearl white, Metallic Grey ( optional) |
|
|
Other Features |
Anti-dust Unit |
|
